INPUT (DC)

• Maximum Recommended PV Array Power
  3900 Wp
• Maximum Input Voltage
  500 V
• Start Up Input Voltage
  125 V
• MPPT Operating Voltage Range
  150 V - 425 V
• Maximum Input Current
  15 A
• Maximum DC Short Circuit Current
  17 A
• Number of Strings per MPPT Input
  1
• Number of Strings per MPPT Input (input A / input B)
  2 / 1

battery

• Battery Voltage Range
  20 V - 30 V
• Compatible battery type
  Lead acid/Lithium
• Maximum Charge/discharge Current
  140 A / 140 A

Inverter Output

• Rated Output Power
  3000 W
• Nominal AC Grid Voltage
  220V/230V/240V
• Output Frequency
  60Hz
• AC Connection
  Single-phase

Input (AC)

• Maximum AC Power
  3000 W
• Maximum AC Apparent Power
  3300 VA
• Maximum AC Current
  14.3 A
• Peak Output Power
  6600 W
• Frequency
  60Hz

Eps Output

EFFICIENCY

• Maximum Efficiency
  97.6 %
• Euro Efficiency
  96.5 %
• MPPT Efficiency
  99 %

PROTECTION & MONITORING

• Over Voltage Protection
  Yes
• Over Current Protection
  Yes
• Over Temperature Protection
  Yes
• RCD Protection
  Yes
• Leakage Current Protection
  Yes
• DC Reverse Polarity Protection
  Yes
• AC Short Circuit Current Protection
  Yes
• Anti-islanding Protection
  Yes
• Insulation Resistance Protection
  Yes
• DC Surge Protection
  Yes
• AC Surge Protection
  Yes
• Ground Fault Current Monitoring
  Yes
• Grid Monitoring
  No
• PV String Current Monitoring
  Yes
• DC Injection Monitoring
  No
• DC Isolation Impedance Monitoring
  No
• LVRT
  No
• Galvanically isolated
  Yes
• PID Prevention
  No
• DC Switch
  No
• AC Switch
  No
• Isolation Protection
  Yes
• Battery Reverse Connection Protection
  Yes
• Battery Start Protection
  Yes
• DC Fuse
  Yes
• AC Surge Category
  II
• DC Surge Category
  II
