SOLAR PANEL 595 WATTS | TRINA SOLAR | Bifacial Half-cut | Monocrystalline | 132 Cells PV Module | Power tolerance 0/+5W | L 2384mm W 1134mm D 30mm | 33.70kg | Material Warranty 12 years | Linear Power Warranty 30 years | Efficiency 22%
Solar Panel Bifacial Half-cut Monocrystalline 595 Wp
Ref: TSM-VERTEXNBD-595WIn Stock
Strengths
- Resistant to harsh environments such as salt, ammonia, sand, high temperature and high humidity areas
Excellent IAM (Incident Angle Modifier) and low irradiation performance, validated by 3rd party certifications
Lower temperature coefficient (-0.30%) and operating temperature
GENERAL DATA
- Monocrystalline
- Framed
- TSM-VERTEXNBD-595W
- 132
DIMENSION AND WEIGHT
- Length 2,384 mmWidth 1,134 mmDepth 30 mm
- 33.70 kg
- 2.70 m²
MECHANICAL CHARACTERISTICS
- Framed
- Anodised Aluminium
- IP68
- Ø 4 mm² / 350 mm
Warranty
- 12 years
- 30 years
- 12 years; 92 %30 years; 87 %
HIGHER LIFETIME POWER YIELD
- 1 %
- 0.4 %
ELECTRICAL DATA AT STC
Standard Test Conditions
Irradiance 1000W/m2, Cell Temperature 25˚C & AM1.5
- 595 Wp
- 40 V
- 14.89 A
- 48.4 V
- 15.8 A
- 22 %
- 0/+5 W
ELECTRICAL DATA AT NOCT
Nominal Operating Cell Temperature:
Irradiance 800W/m2, Ambient Temperature 20˚C & Wind Speed 1m/s
- 454 W
- 37.6 V
- 12.08 A
- 45.6 V
- 12.7 A
TEMPERATURE COEFFICIENTS
- 43 ± 2˚C
- -0.3 %/˚C
- -0.24 %/˚C
- -0.04 %/˚C
MAXIMUM RATING
- IEC 1500 VUL 1500 V
- -40 ˚C ~ +85 ˚C
- 5400 Pa
- 2400 Pa
KEY INFORMATION
- TRINA SOLAR
- CHINA
- MANUFACTURER
- 1997
- Millions $ >100
- >1000 people
- 390 Watts to 700 Watts
Production
- >10000 m²
- 8 Units
- 170,000 MegaWatts
