Solar Panel Half-cut Monocrystalline PERC 555 Wp

SOLAR PANEL 555 WATTS | YINGLI SOLAR | Half-cut | Monocrystalline PERC | 144 Cells PV Module | Grade A | Power tolerance 0/+5W | L 2278mm W 1134mm D 30mm | 28.00kg | Material Warranty 12 years | Linear Power Warranty 25 years | Efficiency 21.5%

Solar Panel Half-cut Monocrystalline PERC 555 Wp

Ref: YL555-49e

In Stock

Strengths

Superior Yield- The large size cell enhances the module’s power output, while the excellent temperature coefficient and comprehensive LID/LeTID degradation suppression technology allow the module to generate more energy yield once in use.

Excellent Durability -The modules meet IEC standard testing requirements and are resistant to salt mist, ammonia, dust and sand, snail trail and PID risks.

Wide Applications - The glass-back sheet structure, special material selection and extra-strong frames effectively enhance the mechanical performance of the modules, their compatibility with mainstream trackers and inverters, and their adaptability to harsh environments.

GENERAL DATA

Solar Cells
Monocrystalline PERC
Panel Type
Framed
Modal Designation
YL555-49e
Grade
A
No. of Cells
144

DIMENSION AND WEIGHT

Dimension
Length 2,278 mmWidth 1,134 mmDepth 30 mm
Weight
28 kg
Panel Area
2.58 m²

MECHANICAL CHARACTERISTICS

Glass Thickness
3.2 mm
Frame Type
Framed
Frame Material
Anodised Aluminium
Encapsulant
EVA
Junction Box
IP67
Junction Box diodes
3
Output Cable
Ø 4 mm² / 300 mm
Connector
MC4

Warranty

Material Warranty
12 years
Linear Power Warranty
25 years
Power Output
1 years; 98 %25 years; 85 %

HIGHER LIFETIME POWER YIELD

First Year Degradation
2 %
Second Year Degradation
2.5 %
Linear Degradation per Year
0.5 %

ELECTRICAL DATA AT STC

Standard Test Conditions

Irradiance 1000W/m2, Cell Temperature 25˚C & AM1.5

Maximum Power Output (Pmax)
555 Wp
Maximum Power Voltage (Vmp)
42.15 V
Maximum Power Current (Imp)
13.17 A
Open Circuit Voltage (Voc)
49.97 V
Short Circuit Current (Isc)
14.04 A
Module Efficiency
21.5 %
Power Tolerance
0/+5 W

ELECTRICAL DATA AT NOCT

Nominal Operating Cell Temperature:

Irradiance 800W/m2, Ambient Temperature 20˚C & Wind Speed 1m/s

Maximum Power Output (Pmax)
412.92 W
Maximum Power Voltage (Vmp)
39.19 V
Maximum Power Current (Imp)
10.54 A
Open Circuit Voltage (Voc)
46.8 V
Short Circuit Current (Isc)
11.34 A

TEMPERATURE COEFFICIENTS

Nominal Operating Cell Temperature:
45 ± 2˚C
Temperature Coefficient of Pmax
-0.35 %/˚C
Temperature Coefficient of Voc
-0.27 %/˚C
Temperature Coefficient of Isc
-0.05 %/˚C

MAXIMUM RATING

Maximum System Voltage
IEC 1500 VUL 1000 V
Maximum Series Fuse
25 A
Operating Temperature Range
-40 ˚C ~ +85 ˚C
Maximum Front Load (Snow Load)
5400 Pa
Maximum Back Load (Wind Load)
2400 Pa
Maximum Hail Resistance (Diameter/Velocity)
25 mm at 23 m/s

KEY INFORMATION

Brand
YINGLI SOLAR
Country
CHINA
Type
MANUFACTURER

FACTORY INSPECTION REPORTS SOLARDROP

Solardrop Laboratory

Founded: 2020
Services: Testing, Certification, Consulting, Training
Revenue: 2 billion (2013)
Total Employees: 200 (2020)

FROM A SINGLE PALLET OF 30 PANELS, DIRECT SUPPLIER! FIRST SOLAR DROPSHIPPER IN THE WORLD
